In Stock
Big Sized Battery Tracker - GPS
Ultra-rugged, long-life battery-powered GPS asset tracking device and Bluetooth® Gateway featuring 10+ years of battery life and tamper detect
- Deploy-once battery life with up to 10+ years movement-based tracking, 2 years at most aggressive (second-by-second) tracking performance
- Bluetooth® 5.2 Gateway for tagged asset management and sensor monitoring
- Powered by off-the-shelf Lithium Thionyl Chloride (LTC) batteries for extreme temperature operation
- Tracks assets when they’re on the move and enters sleep mode when stationary to conserve power
- Battery Meter with ‘Battery Low’ and ‘Battery Critical’ alerts
- Weatherproof and ultra-rugged IP68, IK07 Housing
- Magnetic Tamper Detect
- LTE-M / NB-IoT Connectivity
Spec
SIM Size & Access
:
Internal Nano 4FF SIM
Batteries
:
2 x D Cell (3.7V per cell). Batteries not included.
Supported Battery Types
:
Lithium Thionyl Chloride (LTC)
Dimensions
:
222 x 91 x 41 mm (8.74 x 3.58 x 1.61”)
IP/IK Rating
:
Ultra-rugged and waterproof IP68 and IK06-rated housing
3-Axis Accelerometer
:
3-Axis Accelerometer to detect movement, high G-force events
Onboard Speed and Heading
:
Current speed and heading is reported with each position update
Onboard Temperature
:
The device reports internal temperature which provides an indication of ambient temperature but may not always be precise
Smarts
Battery Life Monitoring
:
"Battery Low” and “Battery Critical” alert level
Geofence Alerts
:
create geofences and alerts if an asset enters or leaves designated locations
Impact Detection
:
Configure impact-detection alerts when G-forces are exceeded by a user-defined threshold
Preventative Maintenance
:
Set reminders based on distance traveled and run hours to reduce maintenance and repair cost
Run Hour Monitoring
:
Capture run hours based on movement to understand and optimize asset utilization
Theft Recovery
:
Switch to Recovery Mode in the case of theft or loss to activate real-time tracking for asset retrieval
Tip Detection & Rotation Counting
:
Axis angle reporting, tip detection and rotation counting
Sleep Mode
:
Stationary devices enter sleep mode until movement occurs to conserve battery life and optimize data usage
Periodic or Movement-Based Tracking
:
Configure parameters to send updates based on set time intervals or when movement occurs. Adaptive tracking technology detects when the device is on the move and increases the update rate, providing detail when you need it while conserving battery when stationary
Onboard Geofencing
:
Geofences can be downloaded directly to the device for enhanced location-based actions and alerts. Maximum of 500 Geofences with up to 100 points per geofence
Rotation Counting
:
Keeps a count of the number of rotations of the device about the Z axis
Tamper Alerts
:
Magnetic tamper switch provides an instant alert if the device is removed from your asset
Tip Detection
:
Define a range of angles that constitutes a ‘tipped’ state and configure alerts
